IP65 80W 12V Safe Junction Box Led Driver 5-1 For Pendants And Dimmable Lighting

Place of Origin : Guangdong, China

Brand Name : KSPOWER

Model Number : KSHP-80W12

Certification : UL FCC CE ROHS SAA CLASS P etc.

MOQ : 2 pieces

Price : $27.80/pieces 2-499 pieces

Warranty(Year) : 5-Year

Lighting solutions service : Lighting and circuitry design

Output Power : 80W

Output Type : PWM

Input Voltage : 100-277V

Output Frequency : 50/60Hz

Product Name : 80W 12V 5 in 1 dimmable Led Driver

Application : LED Strip Light,Pendants, Linears,Cove Lights

Material : Aluminum Case

Warranty : 5 years

Protection : OCP, OVP, SCP, OTP

IP Rate : IP65

Efficiency : ≥90%

Power : 80W

Output : 12V

Contact Now

IP65 80W 12V Safe Junction Box Led Driver 5-1 For Pendants And Dimmable Lighting
IP65 80W 12V Safe Junction Box Led Driver 5-1 For Pendants And Dimmable Lighting

12V 80W Class P driver, 0/1-10V, 10V PWM, Resistance, phase dimming 5 in 1 dimmable LED driver is constant voltage solution, and the perfect choice for under cabinet lighting and other residential and commercial lighting fixture applications.
IP65 80W 12V Safe Junction Box Led Driver 5-1 For Pendants And Dimmable Lighting
Products Description
12V 80W
 12 12.0 V Vdc Volt Volts 12.0V 12volts 12vdc 80 W Watt Watts 80Watt 80Watts
KS-80W is a versatile 80W 5-in-1 universal dimming driver that accepts 100-277VAC input voltage and provides 12V 24V 36V 48V constant voltage output. KS-80W delivers flicker free dimming to 0% on all dinning systems including Triac, 0-10V, 1-10V, PWM, Resistance, MLV, ELV and Incandescent. The high efficiency of the driver and sophisticated overload protection enables the electronics to run cooler and significantly improve reliability while extending product life.
The compact metal case is dry/damp location listed and IP65 rated, making it suitable for a wide range of indoor/outdoor architectural, commercial, industrial, and residential lighting applications. KS-80W is available with or without integrated junction boxes on both the input and output side that have two knockouts each.
IP65 80W 12V Safe Junction Box Led Driver 5-1 For Pendants And Dimmable Lighting
IP65 80W 12V Safe Junction Box Led Driver 5-1 For Pendants And Dimmable Lighting
IP65 80W 12V Safe Junction Box Led Driver 5-1 For Pendants And Dimmable Lighting
IP65 80W 12V Safe Junction Box Led Driver 5-1 For Pendants And Dimmable Lighting
IP65 80W 12V Safe Junction Box Led Driver 5-1 For Pendants And Dimmable Lighting
Features:
* Input Voltage: Universal 100VAC to 277VAC, 50/60Hz for Residential, Commercial, and Industrial Use
* Single Channel & Constant Voltage mode
* Output Voltage: 12Volt
* Driver Type: Class 2 Class P
* Enclosure:LISTED Enclosure with Junction Box / LISTED Enclosure without Junction Box
* Dimming: PWM, TRIAC, 0/1-10V or MLV / ELV Resistance Dimmable Available
* Environmental: Dry and Damp
* Wiring Compartments with Knock-Outs for Clean and Easy Installation
* Current Limiting Overload Protection
* Flicker-Free
* Smooth Ripple Free Output Voltage
* IP65 Rated Enclosure for Indoor and Outdoor Use
* 5-Years Warranty
* UL/cUL CE FCC RoHS ENEC GS Listed, SELV, Type HL

Note:Any custom label/package/case is acceptable, provide OEM and ODM service
IP65 80W 12V Safe Junction Box Led Driver 5-1 For Pendants And Dimmable Lighting
IP65 80W 12V Safe Junction Box Led Driver 5-1 For Pendants And Dimmable Lighting
IP65 80W 12V Safe Junction Box Led Driver 5-1 For Pendants And Dimmable Lighting

IP65 80W 12V Safe Junction Box Led Driver 5-1 For Pendants And Dimmable Lighting
NOW,GET MORE INFORMATIONS OF US !
Company Profile
IP65 80W 12V Safe Junction Box Led Driver 5-1 For Pendants And Dimmable Lighting
IP65 80W 12V Safe Junction Box Led Driver 5-1 For Pendants And Dimmable Lighting
Working Room
IP65 80W 12V Safe Junction Box Led Driver 5-1 For Pendants And Dimmable Lighting
IP65 80W 12V Safe Junction Box Led Driver 5-1 For Pendants And Dimmable Lighting
IP65 80W 12V Safe Junction Box Led Driver 5-1 For Pendants And Dimmable Lighting
IP65 80W 12V Safe Junction Box Led Driver 5-1 For Pendants And Dimmable Lighting
Specification:
IP65 80W 12V Safe Junction Box Led Driver 5-1 For Pendants And Dimmable Lighting
IP65 80W 12V Safe Junction Box Led Driver 5-1 For Pendants And Dimmable Lighting
Nearly ¥3 Million Is Spent On Certification, Just To Make Customers Trust Our Quality
Exhibition
IP65 80W 12V Safe Junction Box Led Driver 5-1 For Pendants And Dimmable Lighting
Product packaging
1.Sample is available.
2.Shipping method: available for express DHL/UPS/FedEx/TNT, Land, Ocean and others.
3. for 60W power adapter : each one put in one small inner brown box, then 50 pcs put in one standard carton.
Package
Piece/Carton(pcs)
Piece Weight(KG)
OEM package
50
0.26
Dimension/Brown Box(mm)
Dimension/Carton(mm)
Gross Weight/Carton(KG)
155*85*35
455*370*175
14
IP65 80W 12V Safe Junction Box Led Driver 5-1 For Pendants And Dimmable Lighting
FAQ
IP65 80W 12V Safe Junction Box Led Driver 5-1 For Pendants And Dimmable Lighting
